電動鎖氣器/鎖氣閥適用于火力發電廠除塵器、空氣預熱器，省煤器等設備的出料口，或干灰輸送管道中，作鎖氣及均勻給料。也可用于化工廠、水泥廠、糧食加工廠部門的氣力運輸管道中?！　‰妱渔i氣器/鎖氣閥結構與型式：　　主要結構有殼體、轉子、傳動結構(擺線針輪減速機、電動機)?！倦娫?微信咨詢：陳經理18068546632】　　裝置型式主要有兩種：　　轉動機構與轉子直線聯接，一字排開--直連式?！　∞D(zhuǎn)動機構與轉子用鏈條搭接--平行軸線式?！　≡谥边B式中，又可細分為帶角鐵支架以配裝臥式減速機(加注B)以及經聯軸節直接聯接立式減速機的型式(加注A)　　備注：可定制非標型?！倦娫?微信咨詢：陳經理18068546632】        《掃二維碼-添加 陳經理 微信-咨詢電動鎖氣器/鎖氣閥》　　Electric air lock/air lock valve is suitable for the discharge ports of dust collectors, air preheaters, economizers and other equipment in thermal power plants, or in dry ash conveying pipelines, for air lock and uniform feeding. It can also be used in pneumatic transportation pipelines of chemical plants, cement plants, and grain processing plants.　　Electric air lock/lock valve structure and type:　　The main structures include shell, rotor, and transmission structure (cycloidal pinwheel reducer, electric motor).　　There are two main types of devices:　　The rotating mechanism is linearly connected to the rotor, arranged in a straight line - direct connection.　　The rotating mechanism and rotor are overlapped with chains - parallel axis type.　　In direct connection, it can be further divided into two types: those with angle iron brackets to install horizontal reducers (note B) and those directly connected to vertical reducers through couplings (note A)　　Note: Non standard models can be customized.

　　鎖氣閥/電動鎖氣器是氣力輸送系統中的關鍵設備，也是除塵和加料系統的常用設備。根據物料的特性、用途和使用條件的不同，電動鎖氣器有多種結構形式。電動鎖氣器的選型要依據被輸送物料的特性如粒度大小、黏附性、溫度、濕度來決定的?！倦娫?微信咨詢：陳經理18068546632】　　鎖氣閥/電動鎖氣器用途：　　電動鎖氣器適用于火力發電廠粉煤灰、煤粉、石膏粉等物料中近距離(300米內)氣力輸送系統。也可用于水泥、冶金、化工等其他行業中粉狀物料的低壓氣力輸送系統。　　常州同得利機械廠主要制造適用于粘性的，含堅硬雜質的以及高溫高壓或高真空情況下使用的電動鎖氣器。以及小尺寸的電動鎖氣器，都是非常規結構非標定制?！倦娫?微信咨詢：陳經理18068546632】       《掃二維碼-添加 陳經理 微信-咨詢鎖氣閥/電動鎖氣器》　　Lock valve/electric lock valve is a key equipment in pneumatic conveying system and a commonly used equipment in dust removal and feeding system. According to the characteristics, uses, and usage conditions of materials, electric air locks have various structural forms. The selection of electric air locks should be based on the characteristics of the conveyed material, such as particle size, adhesion, temperature, and humidity.　　Application of air lock valve/electric air lock:　　Electric air locks are suitable for close range (within 300 meters) pneumatic conveying systems for materials such as fly ash, coal powder, gypsum powder, etc. in thermal power plants. It can also be used in low-pressure pneumatic conveying systems for powdered materials in other industries such as cement, metallurgy, and chemical engineering.　　Changzhou Tongdeli Machinery Factory mainly manufactures electric air locks suitable for use in viscous, hard impurity containing, high-temperature, high-pressure, or high vacuum situations. And small-sized electric air locks are all customized with unconventional structures and non-standard specifications.

　　旋轉供料器，也被稱為旋轉閥、星形卸料閥、關風機、鎖氣閥、旋轉給料器、星型下料器、關風器、電動鎖氣器等，是一種散狀物料輸送的主要設備。它主要由主閥(殼體、端蓋、葉輪、軸承、油封和集氣管等)、電機減速機、防護裝置組成?！倦娫?微信咨詢：陳經理18068546632】　　電動鎖氣器/鎖氣閥的工作原理主要是通過電機驅動葉輪旋轉來實現物料的輸送和鎖氣功能。具體來說：?　　電機傳動：電動鎖氣器通過電機驅動減速機，進而帶動閥體內的葉輪轉子轉動。　　物料輸送：葉輪的旋轉使得物料從上一級管道或輸送斜槽輸送到設備中，然后通過葉輪的旋轉將物料輸送到下一級管道或收料設備。?　　鎖氣功能：在輸送過程中,電動鎖氣器的葉輪不僅負責物料的輸送,還起到密閉作用,防止氣力輸送過程中從出料口吸入空氣，保證系統的正常運作。?【電話/微信咨詢：陳經理18068546632】　　結構特點：電動鎖氣器的葉輪與殼體內壁的間隙很小，有效防止下方低壓泵氣流的上竄，具有良好的鎖氣效果;同時，葉輪采用耐磨材料制成，具有良好的密封性和耐用性。?　　總之，電動鎖氣器通過電機驅動葉輪的旋轉來實現物料的連續均勻給料和氣路的隔斷，確保系統設備的使用需求得到滿足，同時保證物料輸送的安全和效率?！倦娫?微信咨詢：陳經理18068546632】         《掃二維碼-添加 陳經理 微信-咨詢鎖氣閥/旋轉閥》　　The working principle of electric air lock/air lock valve is mainly to achieve material conveying and air lock function by driving the impeller to rotate through the motor. Specifically:　　Motor drive: The electric air lock drives the reducer through the motor, which in turn drives the impeller rotor inside the valve body to rotate.　　Material transportation: The rotation of the impeller causes the material to be transported from the previous pipeline or inclined conveyor to the equipment, and then the material is transported to the next pipeline or receiving equipment through the rotation of the impeller. ?　　Air locking function: During the conveying process, the impeller of the electric air lock is not only responsible for the transportation of materials, but also plays a sealing role to prevent air from being sucked in from the discharge port during pneumatic conveying, ensuring the normal operation of the system. ?　　Structural features: The gap between the impeller of the electric air lock and the inner wall of the housing is very small, effectively preventing the upward movement of the low-pressure pump airflow below, and having a good air lock effect; Meanwhile, the impeller is made of wear-resistant materials, which have good sealing and durability. ?　　In short, the electric air lock achieves continuous and uniform feeding of materials and separation of gas paths through the rotation of the impeller driven by the motor, ensuring that the usage requirements of the system equipment are met while ensuring the safety and efficiency of material transportation.

　　電動鎖氣器/鎖氣閥/星型卸料閥用于旋轉卸料和均勻落料，主要用于粉料和小顆粒物料的氣力送料，是由電動裝置和氣密殼體組成，即可起到均勻落料，也可起到氣料分離的作用?！　×蟼}內物料依靠自重或氣力送料落入電動鎖氣器旋轉的葉輪撥片中，隨著葉輪不斷旋轉物料均勻落下方設備中，由于葉輪和殼體間隙，葉輪低速運行，防止氣力順流或逆向運動，氣壓穩定同時，在氣力送料過程中即可起到供料作用，也可起到密封作用。【電話/微信咨詢：陳經理18068546632】　　電動鎖氣器兩側端蓋設有平衡壓力的聯通管道，可進行壓縮空氣、氮?dú)?、氧氣、氫氣的注入，注入氣體后，兩側氣囊膨起，無論是氣體、還是物料，均可實現零泄漏?！倦娫?微信咨詢：陳經理18068546632】        《掃二維碼-添加 陳經理 微信-咨詢鎖氣閥/卸料閥》　　Electric air lock/air lock valve/star shaped discharge valve is used for rotating discharge and uniform material dropping, mainly for pneumatic feeding of powder and small particle materials. It is composed of an electric device and an airtight shell, which can achieve uniform material dropping or gas separation.　　The materials in the silo are fed by their own weight or pneumatic force and fall into the rotating impeller blades of the electric air lock. As the impeller continues to rotate, the materials evenly fall into the equipment below. Due to the gap between the impeller and the housing, the impeller runs at low speed to prevent the pneumatic force from flowing in the same or opposite direction. At the same time, the air pressure is stable, and it can play a role in feeding and sealing during the pneumatic feeding process.　　The two end caps of the electric air lock are equipped with connecting pipes for balanced pressure, which can inject compressed air, nitrogen, oxygen, and hydrogen. After injecting gas, the airbags on both sides will inflate, achieving zero leakage for both gas and material.

　　本產品鎖氣閥/電動鎖氣器適用于火力發電廠除塵器、空氣預熱器，省煤器等設備的出料口，或干灰輸送管道中，作鎖氣及均勻給料。也可用于化工廠、水泥廠、糧食加工廠部門的氣力運輸管道中?！倦娫?微信咨詢：陳經理18068546632】          《掃二維碼-添加 陳經理 微信-咨詢鎖氣閥》　　This product's air lock valve/electric air lock is suitable for the discharge ports of dust collectors, air preheaters, economizers and other equipment in thermal power plants, or in dry ash conveying pipelines, for air lock and uniform feeding. It can also be used in pneumatic transportation pipelines of chemical plants, cement plants, and grain processing plants.
